用处与详细资料/Brief Introduction：

全自己齿轮泵式膏体酱产品包装机系统是你大公司适合贸易市场市场需要规划设计的高新产品设备。该设备选取SUS304不锈钢板齿轮泵式记量泵制定产品包装，且集自己上盖、自己旋盖、机电专业电气公司为一体化，区域经济常见，拆迁赔偿建筑面积小，丰富操作于医药集团、食材、农药杀菌剂、化工类、画妆品等该行业的粘液产品包装，遵循GMP标准的标准。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

性能/characteristic：

◆选取轴向柱塞泵式计量校准泵继续执行分装，使用很多乳白色度溶剂，误差高；泵的设备构造选取快接式拆装培训机构，有助于清洁、空气消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆注塞泵式计量校准泵火塞环的材料会按照产业及液體基本成分的各不相同运用硅橡胶制品，四氟乙稀或别的材料，独特场所运用陶瓷制品的材料。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC管理模式，变频器变频调速，自己化方面高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不包装，自然筛选性能。Lack of bottle filling, automatic counting function◆装量优化快捷，可以次优化都压力容器检验泵的充填量，也可重要性每个压力容器检验泵做微幅优化；操作方法简易，优化高速 。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆装罐针头要设防滴漏问题安装，充填时溜进瓶底装罐，迟滞持续增长，放到强力气泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆服务器可适于不同的尺寸规格的可乐瓶，调准操作简单，可在短暂间内完工。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆电脑整机按GMP想要设定。The machine designed according to the requirements of GMP

枝术数据/technic parameter：

可用于小瓶年纪Size of bottles	20-1000ml（给出规定订制）20-1000 - ml (according to your need）
实用塑料瓶网套直径Apply the bottle diameter	¢20-¢150mm
实用盖子规格尺寸Apply the lid specifications	¢20-¢70mm
制造特性 production capacity	四头罐装：1000-2500瓶/一小时 Four filling head: 1000-2500 bottles per hour 八头分装：2500-4000瓶/小时英文 Eight head filling: 2500-4000 bottles per hour 12头罐装：4000-6000瓶/H 12 head filling: 4000-6000 bottles per hour
装量误差率The load error	±1%
旋盖合理率Screw cover percent of pass	≥99%
主机电源power supply	380V，50HZ
额定功率power	3.0KW
氧气减压阀gas sources	0.4-0.75MPA
进程掌握speed control	直流变频空调调速器variable speed
