的主要用途是什么与概述/Brief Introduction：

超声波焊接机组为10-20ml内服液液态物质包装产量线中的包括主设配。是由洗瓶、烘干机阶段整体机和包装密封整体机所主成，能主动顺利完成内服液瓶的洗瓶、烘干机阶段、包装和密封等拉伸动作，是内服液产量厂商更非常完美的一起主设配，彻底非常符合GMP必须。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

共同点/Characteristic：

◆装量透彻，应对滴漏问题。包装精度等级高。High filling accuracy.◆变頻无级变速，制作的时间可以调节，能选择不一样的的制作的时间。Frequency control, production speed is adjustable, you can choose a different production rate.◆所以电热器零件均运用国外闻名店牌。All electrical components are imported famous brands.◆定时凸显计数器基本功能。Automatically countting function.◆调节所采用日本的三菱PLCPLC，抗干忧，上班动态平衡。Controlled by Mitsubishi PLC◆使用性能可靠，定期检查维修保养以便于。Stable performance, easy maintenance.◆整套装置看起来应用SUS304不锈铝方案制作、与原辅材料了解的部分应用316L不透钢。整套装置彻底按GMP想要方案。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

技艺性能参数/technical parameters：

支持技术参数/Bottle size	10-20ml
生产销售工作能力/Capacity	60-90瓶/分钟的英文/60-90bottles/min
烘干处理室内温度/Dryer tempreture	100-300°
中水回用水客流量量/Water wastage	0.5m3/h
净化系统水耗量/Purifying water consumption	0.3m3/h
装量表面粗糙度/Filling precision	≤1%
电源适配器/Voltage	380V/50Hz
瓦数/Power	33KW
种植线总长/Dimension	3500×1500×1600mm
