主要用途与筒介/Purpose and introduction：

NQGF型西林瓶粉针洗烘预包装轧盖标贴纸连动线 由QCL型号立试高周波波洗瓶机、AQMR所谓的隧道式制热间歇高压蒸汽高压蒸汽灭菌恒温干燥箱、NQFGX型号车方机螺栓粉剂预包装机、NQ-50轧盖机、NQWTB-120标贴纸汽轮发电机组成，也可单机版适用。满足于7-25ml外形尺寸的西林瓶粉针的生产制造。能做完喷淋头加压、高周波波粗洗、瓶内部水消毒、瓶内部连着分批间歇水消毒、一回吹气、一回鲜新水消毒、连着分批吹气、瓶内部吹气、洗、暖机、烘干设备高压蒸汽高压蒸汽灭菌去热原、制冷、预包装、加塞、轧盖、标贴纸等二十来道生产工序。NLGF schering bottles booster injection wash baked repackaging rolling cover labeling line consists of QCL series vertical ultrasonic bottle washer, ASMR tunnel type hot air circulation oven. NFFGX series CNC screw powder filling machine, NF-50 rolling machine, NFWTB-120 labeling machine, and also can be used stand-alone. Suitable for 7 to 25 ml specification schering bottles of water production. Can finish the spray water injection, ultrasonic thick bottle washing, the outer wall of water flushing, bottle wall continuous secondary circulating water flushing, a blowing, a fresh water rinse, two consecutive bottle blowing, blowing the outer wall, preheating and drying sterilization to pyrogen, cooling, packaging, gasser, cover, labeling and so on more than 20 procedures.

优缺点/characteristic：

◆洗瓶机用机械化手夹瓶，符合许多规格为的西林瓶；Bottle washer adopts manipulator clamp bottle, is suitable for a variety of specifications of schering bottles;◆洗瓶用到雾气喷针回转跟进复制到策略，冲洗成果好，勤俭节约新能源。并下设针架防跳动装备，提生喷针复制到水瓶座的精准度，提高断针物理现象发生；Reciprocating mixer washing bottle with water spray needle track insert way, cleaning effect is good, save energy. And is equipped with needle shake device, improve the accuracy of injection needle inserted into the bottle, reduce breakage phenomenon;◆洗瓶大部分雾水导压管、喷针是独力分手，尽量不要了双向环境污染，按照GMP规范起来想要；Mixer washing bottle the water pipe, injection needles completely separate, to avoid the cross contamination, in line with the GMP requirements;◆洗瓶机进瓶螺丝杆前另装抗震块，有维护螺丝杆，少碎瓶功用；Pieces into the bottle inside the screw before adding buffer block, protect the screw, reduce broken bottle;◆洗瓶机出瓶采取整体布局德国同步操作带，拼接拨瓶块运送西林瓶，作业不稳可信；Pieces out of the bottle inside the whole import synchronous belt, the connection dial the bottle conveying schering bottles, operation is stable and reliable;◆烘干箱按照暧风配置加水，温更加均匀，低碳；Oven adopts hot air circulation heating, temperature uniformity, energy saving;◆烘干箱不设防老是没电保障工作。工作稳定；Mixer oven has suddenly loses power protection function. Run security;◆真空烘箱可配循环往复水冷散热器传动装置，不损耗费屋子里内新风量，减低屋子里内的风压差不失衡的危险因素散热郊果好；Mixer oven can match circulating water cooling device, not loss room air volume, reduce the risk of differential pressure imbalance in room cooling effect is good.◆恒温干燥箱可配压力一键静态动平衡机可以调节操作系统增多户型和恒温干燥箱的压力不静态动平衡机导致的高温环境段偏斜，灌装生产线间洗烘间环境温度升职业技术一品类的相关问题；Mixer automatic oven can match differential pressure balance control system to reduce the room and high temperature oven pressure difference caused by the imbalance of period of migration, filling between wash between baking temperature and so on a series of problems;◆真空烘箱设置DOP测量接口类型(例如气压、风速等级、尘沙离子测量口)；Mixer oven with DOP test interface (including wind pressure, wind speed, dust particle detection);◆烘烤箱急冷段可带迅雷在线灭菌处理功能性(FDA特选)；Mixer oven cooling segment with the function of sterilization (FDA selected);◆烤箱网带可带超音波牵连CIP迅雷在线擦洗程序；Type mixer oven mesh belt with ultrasound scanning CIP online cleaning system;◆烘干箱内腔室可来全东南方向、多方向高压力水消毒；In pieces inside the oven chamber can be all-round, multi-angle high-pressure water flushing;◆分开包装机使用国际性更较为先进的设计的概念概念，拥有高速的度，然而分瓶较准，撤换外形尺寸件省事；Mixer racking machine adopts the most advanced design concept, high speed, and bottles of accurate, replacement of a convenient;◆预包装机采用了讨论交流伺服马达马达安装驱动预包装螺杆式翻转，装量精密；Mixer racking machine adopts ac servo motor drive the repackaging screw rotation, the load accurately;◆分开装袋机应用装量的调节会在触碰屏上推动；Mixer packer adopts the load adjustment directly on a touch screen;◆散装机先选配百级不断循环式层流罩；Mixer packer optional circulating laminar flow hood best level;◆灌装机无瓶为止灌装，无瓶不放塞功能表。Racking machine without stop packing bottle, no bottle no stoppered function.◆整线使用PLC总掌握、变频电机器、摸屏掌握水平，运动固定准确。摸屏可现示各单机版的运动环境，各掌握点的进水管、空气压力、风速、温等现示，各启闭环境和电脑错误代码现示，电脑错误代码自我发展就诊和电脑错误代码剖析及清除技巧。使全生育期间达标会自动掌握，联线有自动化控制动平衡设施，确保生育均衡化准确。The whole line adopts PLC control, inverter, touch screen control technology, stable and reliable running. Touch screen can display the running state of each units, each control point of the water pressure, air pressure, air pressure, temperature, etc, according to the switch state and fault display, fault self-diagnosis and fault analysis and elimination method. Make the whole production process automation control, on-line has the automatic balancing device, ensure production equilibrium is reliable.表明合作方的必须 ，还可供选择：According to the needs of customers, but also available for selection:◆西门子PLC、斯耐德、三菱PLC、台达等品牌标志有效控制模式；Pieces of Siemens, schneider, mitsubishi, Taiwan brands such as control system;◆水、气心理压力、温度及超声检查波密度、尘沙阿尔法粒子、空气流速在线免费论文检测、报警信号、记下、打印图片体系；Pieces of water, gas pressure, water temperature and the intensity of ultrasonic, dust particles, wind speed on-line detection, alarm, record and print system;◆ORABS、CRABS、无菌检测防晒隔离霜器系统。ORABS, CRABS, aseptic isolator system.

新技术性能参数：/technical parameters

型号规格 model

生产销售工作能力production capacity

洗瓶合格达标率Washing bottle percent of pass

洗瓶划痕率Washing bottle breakage

无菌热度sterilizing temperature

预包装误差率The repackaging of error

加塞合适率Gasser percent of pass

冷空气层流卫生度Laminar air cleanliness

真空环境抽速Vacuum pumping speed

电感量 capacitance

电源模块power supply

总剩余电量Total transmission energy

性能尺寸图boundary dimension

7-25ML执行标准西林瓶 7-25ML GBvial

300瓶pcs/分min ～600瓶pcs/分min

≥99%

≤0.1%

300℃-350℃

≤±3%(0.1-10h)

≥99%

100级100c

25m3/H(外配)100cbm/H ～50m3/H(外配)100cbm/H

96kw～235.5kw

380v,50HZ

约 8200KG

约 2000×1750×2370mm
